Standard equipment
• Double-acting cylinder assembly mounted in the press
frame
• Hydraulic/pneumatic adjustment of bed
• Replaceable nose cap
• Flanged piston rod end for tool mounting
• 2 V-blocks/straightening blocks
• Hand pump or motorised hydraulic power unit
• Safety features comply with new European regulations

Function and operation
• Manual pump unit
2-stage single hand operated hand pump unit with
automatic change-over from low to high pressure,
detachable lever, ram return via compressed air supply.

Motorised unit
• Single hand operated 1 or 2-stage oil immersed unit,
with infinite adjustment of the ram speed proportional
to hand control valve lever position.
Hydraulic ram return.

Optional extras
• T-slotted press bed
• Laterally moving cylinder assembly
• Increased stroke length
• Motorised power unit for special applications

Tools/accessories
The FlexiPress can, if required, be supplied complete
with tooling for various applications, e.g.
• Assembly/Disassembly
• Embossing
• Tube and Section Bending
• Straightening
• Flanging
• Punching/Blanking
• Broaching
• Crimping
Detailed literature available on request
