94 dB and 114 dB
SOUND CALIBRATOR
Model : LX107
ISO-9001, CE, IEC1010
FEATURES
- Useful tool to calibrate the
Sound Level meter precisely.
- Frequency : 1000 Hz ± 5 %.
- Sound Pressure Level :
94 dB and 114 dB.
- Suitable Microphone Type :
0.5 inch or 1 inch microphone.
- Power : 2 PCs 006P DC 9V batteres.
GENERAL SPECIFICATIONS
| Frequency | 1000 Hz ± 2 %. |
|---|
| Sound Pressure Level | 94 dB range | 94 dB ± 0.75 dB. |
|---|
| 114 dB range | 114 dB ± 0.9 dB. |
| Suitable Microphone Type | 0.5 inch or 1 inch microphone. |
|---|
| Total harmonic distortion | 94 dB range | ± 2 %. |
|---|
| 114 dB range | ± 5 %. |
| Operating Temp. | 0 to 50℃ (32 to 122 ℉ ). |
|---|
| Power Supply | Heavy duty or Alkaline type, DC 9V battery. 006P,
MN1604 ( PP3 ) or equivalent, 2 PCs. |
|---|
| Power Consumption | Approx. DC 7 mA. |
|---|
| Battery Check | Build in " Battery test indicator " |
|---|
| Dimension | Round 50 mm dia. x 82 mm. |
|---|
| Weight ( including batteries ) | Approx. 350 g/0.77 LB. |
|---|
| Accessories Included | Instruction manual | 1 PC. |
|---|
| 0.5" mic. adapter | 1 PC. |
| Adjust Screw Driver | 1 PC. |
| Carrying case, CA-03 | 1 PC. |
- Insert the microphone of " SOUND LEVEL METER " carefully all the way into
the coupler section of the SC-942.
- Set the " Sound Level Meter " to a range suitable for measuring " 94 dB " or
" 114 dB ".
- Set the " OFF/94 dB/114 dB " to " 94 dB " or " 114 dB " position.
A pure 1,000 Hz tone is produced.
- Adjust the calibration VR (knob) of the " Sound Level Meter ". until that the
display reach to 94.0 dB or 114.0 dB exactly.
* Appearance and specifications listed in this brochure are subject to change without notice.
|
| |
| |
|
