OTHERS > GP > GP-313N

PRODUCT INFORMATION

  • Short wave infrared vehicle baking equipment, high quality prevent dazzling tubes.
  • The working time is 5000 hours with high heating efficiency.
  • The post is made of aluminium alloy, seamless steel tube base and high quality frame.
  • The lamp holder is made of mirror finished stainless steel; Gather heat and dissipate heat intensively.
  • Digital program controlled.
  • 'One key type' interface
  • 2 heating methods: Pulse heat, Full power heat.
  • The heating time can be set from 0-99 minutes.
  • Whole process is automatic, while auto alarm prompt once the work is finished. 4 working models can be set according to different baking time or different paintings.
  • The lamp can operate separately.
  • With professional pneumatic lift, position of the lamps can be adjusted freely. Also, they can turn 330° in 3 directions.

TECHNICAL DATA

  • Model: GP-313N
  • Power Supply: 1PH 220V±20V 50Hz/60Hz
  • Current: 14A
  • Power: 3 x 1000 W
  • Baking Area: 1000 x 1200 mm
  • Baking Distance: 400-600mm
  • Baking Temperature: 60-100℃
  • Primer: 3-5 min
  • The First Putty: 3-6 min
  • The Second Putty: 5-8 min
  • Coating Time: 10-15 min
  • Varnish Time: 10-15 min
  • Lamp Height: 150-2500mm
  • Size: 1760 x 1120 x 200 mm
  • Weight: 66 kg

The products shown above are only a small part of series,
please contact us for your enquiry.
